Description
| MODELS SPEC. | MP1-0832ED | MP1-1032ED | ||||
| POWER | 倍 率 | 有效倍数 | 8x | 10x | ||
| OBJ.LENS DIA. | 物镜直径 | mm | 有效直径 | 32mm | ||
| TYPE OF PRISM | 棱镜类别 | Type / Material | 类别及材料 | BAK4 | ||
| PRISM COATING | 棱镜镀膜 | Yes / No | 是或否 | yes | ||
| NUMBER OF LENS | 透镜组数 | Pieces & Groups | 共多少片及分多少组 | 8pieces6groups | 8pieces6groups | |
| LENS COATING | 透镜镀膜 | CL/FC/BMC/FBMC | 部分或全部或多层膜 | FBMC | ||
| FOCUS SYSTEM | 调焦系统 | Cent. / Ind. / Fix | 中调或分调或定焦 | Cent. | ||
| FOCUSING LENS | 调焦透镜 | Eye. / Obj. / Int. | 目镜或物镜或内调 | Int. | ||
| EXIT PUPIL DIAMETER | 出瞳直径 | mm | 4 | 3.2 | ||
| EXIT PUPIL DIST. | 出瞳距离 | mm | 18 | 15 | ||
| FIELD OF VIEW | 视 场 | ANGLE | 角度 | 7.9° | 7.4° | |
| Ft / 1,000Yds | 尺 | 414 ft | 388 ft | |||
| M / 1,000M | 米 | 138m | 129m | |||
| MIN.FOCAL LENGTH | 最近焦距 | M / Ft. | 米 / 尺 | 2m | 2m | |
| RESOLUTION | 分辨率 | ≤6.8" | ||||
| DIOPTER SYSTEM | 视差补偿 | 左或右的目镜或物镜 | 右目镜 | |||
| DIOPTER COMP. | 视差度数 | ±Optic.Degree | ± 3 | |||
| INTERPUPILLARY DIST. | 目镜相距 | mm | 最阔及最窄时 | 56mm~74mm | ||
| ZOOM SYSTEM | 变焦系统 | Type & Location | 线性或分段 | |||
| WEATHER PROOF | 全 天 候 | Yes / No | yes | |||
| WATER PROOF | 防水结构 | Depth / Time | 深度及时间 | 1m / 30min | ||
| NITROGEN FILLED | 氮气充存 | Yes / No | 有或无 | yes | ||
| EYECUPS SYSTEM | 目罩结构 | Rubber / Pop-up / Twist-up | 可反接橡胶/拉出/旋出 | Twist-up | ||
| POUCH | 软 包 | Yes / No-Mat'l. | 有或无及材料 | yes | ||
| STRAP | 手 带 | Yes / No-Mat'l. | 有或无及材料 | yes | ||
| CLEANING CLOTH | 清 洁 布 | Yes / No | 有或无 | yes | ||
| SILICA GEL | 干 燥 剂 | Yes / No | 有或无 | yes | ||
| UNIT DIAMENSION | 产品尺寸 | mm | 133 | 133 | ||
| UNIT WEIGHT | 产品重量 | gm / oz. | ||||
| GIFT BOX SIZE | 彩盒尺寸 | mm | ||||
| PIECES PER INNER CARTON | 内箱件数 | Pieces / Size | 只数及尺寸 | |||
| INNER CARTON SIZE | 内箱尺寸 | |||||
| PIECES PER SHIPPING CARTON | 装箱件数 | Pieces | ||||
| SHIPPING CARTON SIZE | 装箱尺寸 | Size | cm | |||
| GROSS WEIGHT | 毛 重 | Kg. / Pound | ||||
| NET WEIGHT | 净 重 | Kg. / Pound | ||||
| MODELS SPEC. | MP1-0842ED | MP1-1042ED | ||||
| POWER | 倍 率 | 有效倍数 | 8x | 10x | ||
| OBJ.LENS DIA. | 物镜直径 | mm | 有效直径 | 42mm | ||
| TYPE OF PRISM | 棱镜类别 | Type / Material | 类别及材料 | BAK4 | ||
| PRISM COATING | 棱镜镀膜 | Yes / No | 是或否 | yes | ||
| NUMBER OF LENS | 透镜组数 | Pieces & Groups | 共多少片及分多少组 | 8pieces6groups | 8pieces6groups | |
| LENS COATING | 透镜镀膜 | CL/FC/BMC/FBMC | 部分或全部或多层膜 | FBMC | ||
| FOCUS SYSTEM | 调焦系统 | Cent. / Ind. / Fix | 中调或分调或定焦 | Cent. | ||
| FOCUSING LENS | 调焦透镜 | Eye. / Obj. / Int. | 目镜或物镜或内调 | Int. | ||
| EXIT PUPIL DIAMETER | 出瞳直径 | mm | 5.2 | 4.2 | ||
| EXIT PUPIL DIST. | 出瞳距离 | mm | 18 | 15 | ||
| FIELD OF VIEW | 视 场 | ANGLE | 角度 | 8.3° | 7.3° | |
| Ft / 1,000Yds | 尺 | 435 ft | 383 ft | |||
| M / 1,000M | 米 | 145m | 128m | |||
| MIN.FOCAL LENGTH | 最近焦距 | M / Ft. | 米 / 尺 | 2m | 2m | |
| RESOLUTION | 分辨率 | ≤5.5" | ||||
| DIOPTER SYSTEM | 视差补偿 | 左或右的目镜或物镜 | 右目镜 | |||
| DIOPTER COMP. | 视差度数 | ±Optic.Degree | ± 3 | |||
| INTERPUPILLARY DIST. | 目镜相距 | mm | 最阔及最窄时 | 56mm~74mm | ||
| ZOOM SYSTEM | 变焦系统 | Type & Location | 线性或分段 | |||
| WEATHER PROOF | 全 天 候 | Yes / No | yes | |||
| WATER PROOF | 防水结构 | Depth / Time | 深度及时间 | 1m / 30min | ||
| NITROGEN FILLED | 氮气充存 | Yes / No | 有或无 | yes | ||
| EYECUPS SYSTEM | 目罩结构 | Rubber / Pop-up / Twist-up | 可反接橡胶/拉出/旋出 | Twist-up | ||
| POUCH | 软 包 | Yes / No-Mat'l. | 有或无及材料 | yes | ||
| STRAP | 手 带 | Yes / No-Mat'l. | 有或无及材料 | yes | ||
| CLEANING CLOTH | 清 洁 布 | Yes / No | 有或无 | yes | ||
| SILICA GEL | 干 燥 剂 | Yes / No | 有或无 | yes | ||
| UNIT DIAMENSION | 产品尺寸 | mm | 149 | 149 | ||
| UNIT WEIGHT | 产品重量 | gm / oz. | ||||
| GIFT BOX SIZE | 彩盒尺寸 | mm | ||||
| PIECES PER INNER CARTON | 内箱件数 | Pieces / Size | 只数及尺寸 | |||
| INNER CARTON SIZE | 内箱尺寸 | |||||
| PIECES PER SHIPPING CARTON | 装箱件数 | Pieces | ||||
| SHIPPING CARTON SIZE | 装箱尺寸 | Size | cm | |||
| GROSS WEIGHT | 毛 重 | Kg. / Pound | ||||
| NET WEIGHT | 净 重 | Kg. / Pound | ||||
| MODELS SPEC. | MP1-1050ED | MP1-1250ED | ||||
| POWER | 倍 率 | 有效倍数 | 10x | 12x | ||
| OBJ.LENS DIA. | 物镜直径 | mm | 有效直径 | 50mm | ||
| TYPE OF PRISM | 棱镜类别 | Type / Material | 类别及材料 | BAK4 | ||
| PRISM COATING | 棱镜镀膜 | Yes / No | 是或否 | yes | ||
| NUMBER OF LENS | 透镜组数 | Pieces & Groups | 共多少片及分多少组 | 8pieces6groups | 8pieces6groups | |
| LENS COATING | 透镜镀膜 | CL/FC/BMC/FBMC | 部分或全部或多层膜 | FBMC | ||
| FOCUS SYSTEM | 调焦系统 | Cent. / Ind. / Fix | 中调或分调或定焦 | Cent. | ||
| FOCUSING LENS | 调焦透镜 | Eye. / Obj. / Int. | 目镜或物镜或内调 | Int. | ||
| EXIT PUPIL DIAMETER | 出瞳直径 | mm | 4.9 | 4.2 | ||
| EXIT PUPIL DIST. | 出瞳距离 | mm | 18 | 15 | ||
| FIELD OF VIEW | 视 场 | ANGLE | 角度 | 6.5° | 6.1° | |
| Ft / 1,000Yds | 尺 | 341 ft | 320 ft | |||
| M / 1,000M | 米 | 114m | 107m | |||
| MIN.FOCAL LENGTH | 最近焦距 | M / Ft. | 米 / 尺 | 2.5m | 2.5m | |
| RESOLUTION | 分辨率 | ≤4.3" | ||||
| DIOPTER SYSTEM | 视差补偿 | 左或右的目镜或物镜 | 右目镜 | |||
| DIOPTER COMP. | 视差度数 | ±Optic.Degree | ± 3 | |||
| INTERPUPILLARY DIST. | 目镜相距 | mm | 最阔及最窄时 | 58mm~74mm | ||
| ZOOM SYSTEM | 变焦系统 | Type & Location | 线性或分段 | |||
| WEATHER PROOF | 全 天 候 | Yes / No | yes | |||
| WATER PROOF | 防水结构 | Depth / Time | 深度及时间 | 1m / 30min | ||
| NITROGEN FILLED | 氮气充存 | Yes / No | 有或无 | yes | ||
| EYECUPS SYSTEM | 目罩结构 | Rubber / Pop-up / Twist-up | 可反接橡胶/拉出/旋出 | Twist-up | ||
| POUCH | 软 包 | Yes / No-Mat'l. | 有或无及材料 | yes | ||
| STRAP | 手 带 | Yes / No-Mat'l. | 有或无及材料 | yes | ||
| CLEANING CLOTH | 清 洁 布 | Yes / No | 有或无 | yes | ||
| SILICA GEL | 干 燥 剂 | Yes / No | 有或无 | yes | ||
| UNIT DIAMENSION | 产品尺寸 | mm | 167 | 167 | ||
| UNIT WEIGHT | 产品重量 | gm / oz. | ||||
| GIFT BOX SIZE | 彩盒尺寸 | mm | ||||
| PIECES PER INNER CARTON | 内箱件数 | Pieces / Size | 只数及尺寸 | |||
| INNER CARTON SIZE | 内箱尺寸 | |||||
| PIECES PER SHIPPING CARTON | 装箱件数 | Pieces | ||||
| SHIPPING CARTON SIZE | 装箱尺寸 | Size | cm | |||
| GROSS WEIGHT | 毛 重 | Kg. / Pound | ||||
| NET WEIGHT | 净 重 | Kg. / Pound | ||||
